Unused Waukesha Transformer
Product ID: 5717
A 2002 Waukesha Transformer, Never put in service, 12/16/20 MVA, 34.5 kV Delta 4.16/2.4 kV Wye
- Size: 12/16/20 MVA
- HV_H: 34500
- HV 2:
- Dual HV:
- HV TC Type: Off Load Tap Changer
- LV_1_X: 4160
- LV_2_Y:
- LV2 Type:
- Dual LV:
- LV TC Type:
- See Notes: Yes
- High Voltage Vector: Delta
- Low Voltage Vector: Wye
- High 2 Voltage Vector:
- Low 2 Voltage Vector:
- High Voltage Bushing: Sidewall Tank Mounted
- Low Voltage Bushing: Sidewall Tank Mounted
- HV2 Bushing:
- LV2 Bushing:
- Station Type: Substation Step down
- Live Dead:
- Feed:
- Type: Mineral Oil Filled
- Width: 150
- Length: 159
- Height: 160
- Weight: 64800
- Phase: 3
- HZ: 60
- DOM: 2002
- MFG: Waukesha
