Delta Star Dual High Voltage 115 kV X 69 kV
Product ID: 5722
Delta Star Dual High Voltage 115 kV X 69 kV Delta Primary, 25 kV Wye Secondary with Load Tap Changer. Mineral Oil Filled Substation Stepdown Transformer
- Size: 5/5.6 MVA
- HV_H: 115000
- HV 2: 69000
- Dual HV: 1
- HV TC Type: Off Load Tap Changer
- LV_1_X: 25000
- LV_2_Y:
- LV2 Type:
- Dual LV:
- LV TC Type: Load Tap Changer
- See Notes: Yes
- High Voltage Vector: Delta
- Low Voltage Vector: Wye
- High 2 Voltage Vector:
- Low 2 Voltage Vector:
- High Voltage Bushing: Top cover mounted Segment 3
- Low Voltage Bushing: Top cover mounted Segment 1
- HV2 Bushing:
- LV2 Bushing:
- Station Type: Substation Stepdown
- Live Dead:
- Feed:
- Type: Mineral Oil Filled
- Width: 152
- Length: 124
- Height: 154
- Weight: 80907
- Phase: 3
- HZ: 60
- DOM:
- MFG: Delta Star
