Alstom Substation
Product ID: 5716
5 MVA Alstom End-End Unit Substation, 33 kV Delta Primary, 4.16/2.4 kV Wye Secondary, Mineral Oil Filled
- Size: 5/6.25 MVA
- HV_H: 33000
- HV 2:
- Dual HV:
- HV TC Type: Off Load Tap Changer
- LV_1_X: 4160
- LV_2_Y:
- LV2 Type:
- Dual LV:
- LV TC Type:
- See Notes: Yes
- High Voltage Vector: Delta
- Low Voltage Vector: Wye
- High 2 Voltage Vector:
- Low 2 Voltage Vector:
- High Voltage Bushing: Sidewall Tank Mounted
- Low Voltage Bushing: Sidewall Tank Mounted
- HV2 Bushing:
- LV2 Bushing:
- Station Type: Substation Step down
- Live Dead:
- Feed:
- Type: Mineral Oil Filled
- Width:
- Length:
- Height:
- Weight: 24450
- Phase: 3
- HZ: 60
- DOM: 2002
- MFG: Alstom
